p32 Finn Power Air Conditioning 2" High Pressure Rubber Hydraulic Hose Crimpers

FOB Reference Price:Get Latest Price
US $999-2,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Tianjin, China (Mainland)
Brand Name:
QTD
Model Number:
QTD-51
Voltage:
220V/380V
Power(W):
3KW
Dimension(L*W*H):
830*820*860
Weight:
300Kg, 360KG
Certification:
ISO
Warranty:
1 year
After-sales Service Provided:
Engineers available to service machinery overseas
Product type:
QTD-51
Function:
Crimping hose with fitting
Crimping range:
1/4''-2''
Dies:
10 Sets (16, 19, 23, 26, 31, 36, 41, 47, 55, 63)
Crimping Force:
449T
Application:
Lock Fittings
Hydraulic Hose:
2"6SP
working voltage:
220v/380v
SupplyAbility
SupplyAbility:
900 Set/Sets per Month
Packaging & Delivery
Packaging Details
wood cases
Port
any port of China
Lead Time :
we have it in stock

p32 Finn Power Air Conditioning 2" High Pressure Rubber Hydraulic Hose Crimpers







Crimping range6mm-51mm
Rated pressure31.5Mpa
The largest crimping pressure449T
Ruler precision0.02mm
Oil pump out-let quantity

5ml/rad/3kw  (380V)

5ml/rad/3kw  (220V)

Weight360kg
Stoke850 stoke/hour
Dimension830mm*820mm*860mm
Die10 sets

1. Put the hose into the crimping head .(The first crimp turn the key to manual position)

2. Setting the crimping length one time.(General put the hose and fitting in middle of crimping head)

3. Press the lock button then machine will crimping still it stopped .

4. Turn the function key to semi-automatic position indicator light bright , put hose and fitting into crimping head press the crimping button or step pedal switch one time, the piston will moving forward, the die seat fold, when it reach the preadjustment scale mark, it will opening and return to the first position, waiting for the next operation.



Matters need attention of hydraulic hose crimper china:

1.motor start:pay attention to the direction of rotation of the motor and pump rotation direction or arrow direction.

2.before the operation:check the hydraulic oil tank and oil level matching.rection or arrow direction.

3.normal operation:the first 30 minutes of running after normal use.

4.hydraulic oil:normally we use mobile #46 Hydraulic oil, if your country do not have this brand you can buy the better one, if the hydraulic oil clean enough, it is good to the machine.

5.system failure: system failure,don not blindly processing,in accordance with the "first easy hind difficult,after the first" sequence analysis or find professional repair personnel to solve problems.

Safety tipes of hydraulic hose crimper china:

1.Read operation specifications over and over again knowing to control machinery principle last the day after tomorrow going to post.

2.Observe the operation norm strictly being on the alert paying attention to safety.

3.The periodic inspection maintenance adds enough wetting oil.



Q1: Are you a manufacturer or trading company?
  A1: We are a specialized manufacturer.
Q2: How about discount?
  A2: Price is based on products and order quantity.
Q3: How about your after-sales service?
  A3: As a manufacturer, we offer promote technology support for all problems and questions.
Q4: Where is your factory located in?
  A4: Our factory is located in tianjin city,China.
Q5: How does your company control the quality?
  A5: Quality first. In order to guarantee high quality for our products, TY always makes a serious inspection for all products and raw materials in strict procedure.
Q6:How to order the products?
  A6:Send the inquiry with detail item desciption or with Model number.
Q7:What is your terms of delivery?
  A7:We accept FOB,CIF etc.you can choose one which is more convenient.
